Venting hob Novy Panorama Pro 120 cm
Type number: 42120
42120 Venting hob Novy Panorama Pro 120 cm Black
- Efficient source extraction: tower height adjustable to 10, 20, and 30 cm, as well as variable
- Versatile extractor tower: Semi-transparent and functions as a splash guard
- Five cooking zones for optimal cooking convenience
- Timeless design: stylish and functional downdraft extraction
- Easy maintenance: quick and simple to clean
- Flexible installation: Surface or flush mount
£ 5,299 including VAT
Specifications
Weights & Dimensions
Product Depth
520 Millimetre
Product Width
1180 Millimetre
Product Height
65 Millimetre
Product Weight
81.2 Kilogram
Width
120 cm
Product Dimensions (WxDxH) (mm)
1180 MILLIMETER X 520 MILLIMETER X 65 MILLIMETER mm
Energy Specifications
Electrical Volts
230-400V
Electrical Connection (Plug) Type
Schuko
Electrical Total Wattage
10850 Watt
Maximum power cooker hood
450 Watt
Length power supply cable
1.2 Metre
Electrical frequency
50-60 Hertz
Maximum power induction hob
10400 Watt
Electrical Connection Location
Right
Maximum power spare part (W)
450
Installation Details
Position exhaust
Center bottom
Functions and Features
Flexzone
2
Auto stop
Timer Type
Timer, timer per zone, automatic cooking
Control type
Touch control
Novy Connect
Standard
Chef function
Recirculation
Default setting
Control method
Slider touch control
Grill function
Stop & Go function
Remote Control
Sound absorber
Integrated
Childproof lock
InTouch function
Not applicable
Number of Motors
3
Automatic Power revert (minutes)
6 Minute
Pot move function
Delayed switch off
Info display color
White
Fan Motor Location
Integrated
Keep Warm Function
70°C
Number of Fan Speeds
5 + 3
Exterior Finish Colour
Black
Grease filter
42120510,42120515
Functioning mode
Duct out & recirculation
Safety time-switch-off
Finishing
Glossy glass
Number of Grease Filters
2
Residual heat indication in worktop
Yes
Automatic pan recognition
Diameter outlet
222x89
Delayed Switch Off Minutes
30, 10
Flexzone activation
Semi-automatic
Tower height (cm)
Freely adjustable (10-30)
Grease filter cleaning indication
Recirculation filter cleaning indication
Regulation, Compliance, Certifications
Annual Energy Consumption (AEChood)
65,4
Time increase factor (f)
1.10
Max pressure duct out speed 1
28 Pascal
Sound regulation
DIN 45625-2
Energy efficiency class (EEIhood)
B
Airflow duct out max powerspeed (Qboost)
1009 Cubic meter per hour
Max pressure duct out at minimum speed
28 Pascal
Lighting efficiency class (LEhood)
Niet van toepassing
Sound power duct out at minimum speed (LWAmin)
35 dB(A)
Airflow duct out at min speed (Qmin)
237 Cubic meter per hour
Max pressure duct out at maximum powerspeed
416 Pascal
Airflow at best efficiency point (QBEP)
446.4 Cubic meter per hour
Sound pressure duct out at minimum speed
22 dB(A)
Fluid dynamic efficiency class (FDEhood)
B
Sound power duct out at max powerspeed (LWAboost)
70 dB(A)
Sound pressure duct out at max powerspeed
56 dB(A)
Sound power duct out at max continuous speed (LWAmax)
61 dB(A)
Grease filtering efficiency class (GFEhood)
C
Max pressure duct out at max continuous speed
191 Pascal
Airflow duct out at max continuous speed (Qmax)
689 Cubic meter per hour
Sound pressure duct out at max continuous speed
48 dB(A)
Additional Technical Specifications
Glass edge
Rounded border
Cleaning products
906091, 906092, 906093
Lighting
710201-p3,710202-p3,710301-p3,710302-p3,740201,740202,740301,740302
Wipeguard function
Main on/off switch
Window switch
990036
Free airflow
1530 Cubic meter per hour
Number of Cooking Zones
5 zones
Recirculation box
7941400, 7942400, 7943400
Cut-out worktop (WxD) (mm)
1160 x 490
Cooking accessories
1700092, 1700093, 1700095, 1700099, 1700100
Recirculation filter
98001
Depth backside cut out opening
38 Millimetre
Voltage cooker hood (V)
230
Dimensions cooker hood (WxDxH) (mm)
1100 × 162 × 760-840
Additional accessories
1821400
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 2 | Left Center | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 3 | Center | 280 | Induction cooking zone | 2300 Watt | 3000 Watt |
| Cooking zone 4 | Right Center | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 5 | Right | 200x240 | Induction cooking zone | 2100 Watt | 3000 Watt |
