Venting hob Novy Easy 80 cm
Type number: 1851
1851 Venting hob Novy Easy 80 cm Black
- Optimised airflow due to elegant finish
- Easy Maintenance
- Extra large cooking surface
- 4 cooking zones with useful functions
- Flexible Installation: surface and flush installation possible
Specifications
Weights & Dimensions
Product Depth
520 Millimetre
Produktbreite
800 Millimetre
Product Height
215 Millimetre
Product Weight
18.3 Kilogram
Width
80 cm
Product Dimensions (WxDxH) (mm)
800 Millimeter X 520 Millimeter X 215 Millimeter
Energy Specifications
Electrical Volts
230-400V
Electrical Total Wattage
7568 Watt
Length power supply cable
1.5 Metre
Electrical frequency
50-60 Hertz
Electrical Connection (Plug) Type
Other
Electrical Connection Location
Right
Installation Details
position_exhaust novy
Left
Functions and Features
Flexzone
2
Auto stop
Chef function
Grill function
Stop & Go function
Childproof lock
Number of Motors
1
Automatic Power revert (minutes)
10 Minute
Pot move function
Delayed switch off
Fan Motor Location
Integrated
Number of Fan Speeds
9 + power
Exterior Finish Color
Black
Grease filter
99003
Safety time-switch-off
Number of Grease Filters
1
Automatic pan recognition
Diameter outlet
222x89
Grease filter cleaning indication
Recirculation filter cleaning indication
Timer Type
Timer, timer per zone, automatic cooking
Recirculation
Not Applicable
Control method
Slider touch control
Info display color
Red
Keep Warm Function
70°C
Finishing
Glossy glass
Residual heat indication in worktop
Yes
Delayed Switch Off Minutes
10
Flexzone activation
Semi-automatic
Regulation, Compliance, Certifications
Airflow duct out speed 1
186 Cubic meter per hour
Time increase factor (f)
0.60
Sound power duct out speed 1
46 dB(A)
Max pressure duct out speed 1
32 Pascal
Max pressure duct out speed 4 (Pa)
452 Pascal
Sound regulation
DIN 45625-2
Sound pressure duct out speed 1
34 dB(A)
Airflow duct out max powerspeed (Qboost)
610 Cubic meter per hour
Max pressure duct out at minimum speed
32 Pascal
Airflow duct out at min speed (Qmin)
186 Cubic meter per hour
Max pressure duct out at maximum powerspeed
452 Pascal
Airflow at best efficiency point (QBEP)
288.1 Cubic meter per hour
Sound pressure duct out at minimum speed
34 dB(A)
Sound pressure duct out at max powerspeed
58 dB(A)
Sound power duct out at max continuous speed (LWAmax)
66 dB(A)
Max pressure duct out at max continuous speed
263 Pascal
Airflow duct out at max continuous speed (Qmax)
520 Cubic meter per hour
Sound pressure duct out at max continuous speed
54 dB(A)
Annual Energy Consumption
17,9
Energy efficiency class (EEIhood)
A+++
Lighting efficiency class (LEhood)
Niet van toepassing
Fluid dynamic efficiency class (FDEhood)
A
Grease filtering efficiency class (GFEhood)
B
Additional Technical Specifications
Lighting
710101-p3,710102-p3,710201-p3,710202-p3,740101,740102,740201,740202
Main on/off switch
Free airflow
750 Cubic meter per hour
Number of Cooking Zones
4 zones
Depth backside cut out opening
55 Millimetre
Voltage cooker hood (V)
230
Cooking Surface Configuration
| Cooking zone | Position | Zone Dimension (mm) | Cooking zone type | Power Rating | Power Rating (Power) |
|---|---|---|---|---|---|
| Cooking zone 1 | Left Front | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 2 | Left Rear | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 3 | Right Rear | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
| Cooking zone 4 | Right Front | 240x210 | Induction cooking zone | 2100 Watt | 3000 Watt |
Cleaning products
906091, 906092, 906093, 906094
Cooking accessories
1700092, 1700093, 1700095, 1700099, 1700100
