Telescopic hood Novy Telescopic 90 cm
Type number: 693
693 Telescopic hood Novy Telescopic 90 cm Stainless steel
- Can be integrated flush with the wall cabinet
- telescopic slide for optimum capture of cooking vapours
- sufficient space for a herb rack
- glass visor for a transparant look
- LED lighting (2700K)
- electronic control with extra functions
Specifications
Weights & Dimensions
Product Depth
290.00 Millimetre
Product Width
898.00 Millimetre
Product Height
348.00 Millimetre
Product Weight (kg)
18.50 Kilogram
Product Dimensions (WxDxH)
898 Millimeter X 290 Millimeter X 348 Millimeter
Energy Specifications
Electrical Volts
230V
Electrical Total Wattage
200.00 Watt
Fuse (A)
10
Length power supply cable (m)
1.10 Metre
Electrical Hertz (frequency)
50 Hertz
Electrical Connection (Plug) Type
Schuko
Installation Details
Diameter duct (mm)
150.00 Millimetre
Max mounting height gas hobs (mm)
750.00 Millimetre
Min mounting height gas hobs (mm)
650.00 Millimetre
Max mounting height ceramic hobs (mm)
750.00 Millimetre
Min mounting height ceramic hobs (mm)
600.00 Millimetre
Max mounting height induction hobs (mm)
750.00 Millimetre
Min mounting height induction hobs (mm)
650.00 Millimetre
Position exhaust
Boven
Installation Type
Built-in appliance
Depth cut out opening (mm)
180
Width cut out opening (mm)
860
Dimensions cut-out opening (WxD) (mm)
860 x 180
Advised mounting height gas hobs (Hmin-Hmax) (mm)
650 - 750
Advised mounting height induction hobs (Hmin-Hmax) (mm)
650 - 750
Functions and Features
Auto stop
Yes
Novy Connect
Not applicable
Sound absorber
Integrated
InTouch function
Optional
Number of Motors
2
Automatic Power revert (minutes)
6.00 Minute
Delayed switch off
Yes
Fan Motor Location
Integrated
Number of Fan Speeds
3 + power
Grease filter
609014
Number of Grease Filters
2
Diameter outlet (mm)
150
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Recirculation
Optional
Control method
Push buttons
Finishing
Stainless steel
Delayed Switch Off Minutes
10
Regulation, Compliance, Certifications
Airflow duct out speed 1 (m³/h)
259.00 Cubic meter per hour
Airflow duct out speed 2 (m³/h)
356.00 Cubic meter per hour
Airflow duct out speed 3 (m³/h)
436.00 Cubic meter per hour
Time increase factor (f)
1.40
Sound power duct out speed 1 (dB(A))
43.00 dBA
Sound power duct out speed 2 (dB(A))
50.00 dBA
Sound power duct out speed 3 (dB(A))
55.00 dBA
Max pressure duct out speed 1 (Pa)
153.00 Pascal
Max pressure duct out speed 2 (Pa)
225.00 Pascal
Max pressure duct out speed 3 (Pa)
262.00 Pascal
Sound regulation
EN 60704-2-13
Sound pressure duct out speed 1 (dB(A))
32.00 dBA
Sound pressure duct out speed 2 (dB(A))
39.00 dBA
Sound pressure duct out speed 3 (dB(A))
43.00 dBA
Nominal power of lighting system (WL) (W)
6.40 Watt
Airflow duct out max powerspeed (m³/h) (Qboost)
605.00 Cubic meter per hour
Max pressure duct out at minimum speed (Pa)
153.00 Pascal
Airflow duct out at min speed (m3/h) (Qmin)
259.00 Cubic meter per hour
Airflow at best efficiency point (QBEP) (m³/h)
346.00 Cubic meter per hour
Sound pressure duct out at minimum speed (dB(A))
32.00 dBA
Sound pressure duct out at max powerspeed (dB(A))
50.00 dBA
Sound power duct out at max continuous speed (dB(A))
55.00 dBA
Max pressure duct out at max continuous speed (Pa)
262.00 Pascal
Airflow duct out at max continuous speed (m3/h) (Qmax)
436.00 Cubic meter per hour
Sound pressure duct out at max continuous speed (dB(A))
43.00 dBA
Average illumination of the lighting system on the cooking surface (Emiddle) (lx)
299.00 LUX
Annual Energy Consumption
86,2
Energy efficiency class (EEIhood)
C
Lighting efficiency class (LEhood)
A
Lighting efficiency index (LEhood)
47
Fluid dynamic efficiency class (FDEhood)
D
Grease filtering efficiency class (GFEhood)
E
Additional Technical Specifications
Lighting
906303
